Colorado's Exclusive Grand Design Lineage Motorhome Dealer
The Lineage Series F's Fox Factory Suspension isn't just truck-tough – it's fully adjustable at each corner for the new Lineage Series F. Turn the dial for highway comfort, towing stability, or off-road 4x4 capability. Finally, a Super C that handles like your truck, everywhere you want to go.
Windish RV is Grand Design's exclusive Lineage Motorhome dealer in Colorado. You are able to see this new addition to the Grand Design lineup at any of our 3 convenient front range locations, Lakewood, Longmont and Colorado Spring. To schedule your first look and to receive more information, please fill out the form below.
Grand Design Lineage Video
Schedule Exclusive Tour
Schedule an exclusive first look at Grand Design's new Series Lineage Series F, available only at Windish RV in Colorado! Just fill out the form below to learn more and schedule today!
Specifications
| CHASSIS AND DRIVETRAIN | |
| Chassis | Ford F-600 Cab Chassis 4x4 |
| Engine | 6.7L 4V 8-Cylinder |
| Transmisson | Torq Shift 10 speed automatic |
| HP | 330 HP |
| Torque | 950 ftlb @ 1800rpm |
| OVERALL SIZE | |
| Exterior Length | 33' 9" |
| Exterior Width | 8' 4" |
| Exterior Height | 12' 3" |
| Interior Height | 81" |
| Awning Length | 13' |
| WEIGHTS | |
| GAWR Front | 7,500 lbs |
| GAWR Rear | 15,500 lbs |
| GVWR | 22,000 lbs |
| GCWR | 43,500 lbs |
| APPLIANCES | |
| Hot Water Heater | Tankless |
| Furnance | 30K BTU |
| Refrigerator | 12V 10 cu/ft |
| CAPACITY | |
| Diesel Fuel Capacity | 66.5 gal |
| DEF | 7.2 gal |
| Fresh Water | 79 gal |
| Grey Water | 66 gal |
| Black Water | 45 gal |
| LPG | 20.3 gal / 88 lbs |
| RUNNING GEAR | |
| Axles | 2 |
| Tire Size | LT245/70 Rx19.5G |
| Wheelbase | 245" |
| DIMENSIONS | |
| Bed Size | 70"x80" King Bed |
| Dinette | 68" x 42" |
| Sofa | 68" x 36" |
| QUANTITIES | |
| Slideout | 2 |
| Sleeping Capacity | 5 |
| Sleeping Areas | 3 |
| Seat Belt Positions | 6 |
| POWER | |
| Coach Batteries | 310 Amp-Hr |
| Solar | 1,000 Watts Solar |
